NSR NVR-3000 VHF Radio.
The NVR-3000 meets the Class A standard for VHF DSC according to ITU and IMO regulations and can be part of the built-in GMDSS package for A1, A2 or A3 vessels.
Interfaces to the VDR and BAM systems are available on the NVR-3000. NVR-3000 meets the requirements of ITU-R M.493-15, IMO M302 (87), IMO MSC.1/Circ.1460/Rev.3, IEC 61097-3, IEC 61097-7, IEC 62923-1 , IEC 62923-2 and IEC 61162-1.
Meet the latest ITU standards.
Large 7-inch color display
Button and touchscreen controls
4-digital channels available
Dual Handsets operational
Data interface to BAM system/INS
DNV type approval
CCS type approval
Specifications NSR NVR-3000 VHF RADIO:
TX Frequency: 156.000～157.425MHz
RX Frequency: 156.000～163.425MHz
Working Channel: ITU
DSC Watch CH:CH70
TX Power: 25W(high)/1W(low)
RX Sensitivity: ≤2μV(SINAD=20dB)
Display: 7 inch，color LCD，touch screen
GNNS Input:RS422，4800bps
VDR Output:600Ω balanced
BAM/INS I/O:
RS422,4800bps
Printer I/O: RS232,4800bps
Power Supply: 24 VDC(max 4A)
Weight 3kg
IP Grade IP22
