Raymarine Element 9 HV with 1.2 megahertz HyperVision sonar technology provides a very sharp image of the underwater world. The increased resolution of DownVision, SideVision, RealVision 3D and reach a new level of precision and fish recognition. You will see structures, vegetation and fish with fantastic, lifelike clarity. The Element CHIRP Sonar/GPS series gives you more control when searching for fish and their habitat.
The Raymarine Element 9 HV has a rugged 9-inch optically bonded LCD display that is easy to read even in sunlight. It uses a button system with intuitive controls.
Raymarine Element 9 HV Specifications:
Dimensions 287 x 161 x 62 mm
Resolution 800 x 480 WVGA
Without touchscreen
Brightness 1,500 nit
Viewing angle: 50/60/70/70 (top/bottom/left/right)
Power consumption: 20 watts
Built-in GNSS receiver: GPS/GLONASS
Built-in CHIRP sonar, DownVision, SideVision, RealVision™ 3D
15-pin HyperVision connector
1x NMEA2000 port (DeviceNet microC)
SeaTalkng: Requires A06045 DeviceNet female (F) adapter cable
WiFi - 802.11 b/g/n
Bluetooth 4.0
1x microSD slot
Manual HV-100 HyperVision transducer.
Manual Raymarine Element 9 HV.
